AJ Garden Bollard
About the AJ Garden Bollard
This outdoor lamp emits a pleasant, fully shaded, downwardly directed, glare-free light. It is available in two different heights and has a fixed head. The inside of the shade is painted white to ensure a soft and pleasant reflection of light. The shape of the shade provides superior lighting, allowing an optimal view of its surroundings. The garden bollard can be fitted with three different installation types – namely a base plate, a spike, or an anchor.
- Light sourceLight source LED 3000KLumen: 454ComplianceIngress protection: IP 65. IK06Other informationThe adapter is positioned externally from the fixture and can run up to 6 bollards. Maximum distance to last bollard is 30m. Spike: Plug and play. Let the enclosed cables run over the ground. Uses standard cables and connectors which are supplied. Anchor/Base: Requires certified electrician. Use installation tube for inground installation, with enclosed cables running inside, for legal fixed installation. LED replacement kit available. Replacement of the built-in LED requires a certified electrician.
- MaterialsHead: Cast aluminum. Stem and base plate: Stainless steel. Spike: Cast aluminum with ABS housing. Anchor: Steel. Diffuser: Injection-molded opal PC.FinishOutside: Black textured surface, powder-coated. Inside: White, wet-painted.
Size (in.): 90 (width) x 504 (Height) x 90 (Length)Weight:0.0 lbs- This product is compliant with the requirements contained in the European Directives, RoHS Directive 2011/65 and 2015/863. This product is designed so that 100% of the product can be disassembled and reused. Louis Poulsen is part of ELRETUR which ensures that electronic waste (WEEE) across of Europa is reused. This product must be treated as electronic waste. The product is packaged in a fabric bag and a cardboard box. The cardboard is made from min. 75% recycled fibremass. Additional cardboard material comes from FSC approved sources.Download environmental product information
- The bollard requires a separate, 24V DC power supply. Choice of 3 different mounting types. Spike mounted bollard: For use in soil or gravel; includes weather-proof cables and connectors for above-ground runs. Plug and play. Anchor mounted bollard: for casting in new concrete pad. Base mounted bollard: Includes baseplate for anchoring to decks and floors. Anchor or Base mounted bollards: installation determined by certified electrician with below ground cabling and conduit.Mounting instructions
- GARD PWR SUP USA 24VDC 100W BASE-ANCHOR#Item no:10000158964002$ 260GARD PWR SUP USA 24VDC 100W SPIKE#Item no:10000158965002$ 260GARDEN T-CONNECTORItem no:5747405303002$ 30
Similar Products
Installation Guide
AJ GARDEN BOLLARDS are available in three versions: with anchor, baseplate, or spike.
The bollard is run by an external driver/adaptor (24V) that must be bought separately. A maximum of six AJ Garden bollards (6,5W) can be run by one adaptor.
Anchor
Anchor unit to be fixed in concrete.
Requires installation by certified electrician.
24V:
Bollard with anchor, T-connector, and 5 m. cable with plugs.
Bollard with anchor unit to be fixed in concrete. Use installation tubes for inground installation, with enclosed cables running inside for legal fixed installation.
Adapter must be bought separately.
Baseplate
Baseplate for mounting on a surface.
Requires installation by certified electrician.
24V:
Bollard with baseplate, T-connector, and 5 m. cable with plugs.
Two options for installation:
1. Mounting on a surface with overground installation. Enclosed cables running over the ground. When using T-connector for multiple bollards the connector must be easily accessible. The cables must be fixed for legal fixed installation.
2. Mounting on a surface with in-ground installation. Use installation tubes for in-ground installation, with enclosed cables running inside, for legal fixed installation.
Adaptor must be bought separately.
Spike
For direct placement into the ground.
Plug-and-Play.
24V:
Bollard with spike, T-connector, and 5 m. cable with plugs.
Put the bollard with the spike into the ground. Let the enclosed cable 5 m. run over the ground. The bollard is connected to the
adaptor using standard plugs delivered with the fixture. Plug-and-Play.
Adaptor must be bought separately.
Heritage meets modern
Originally designed by Arne Jacobsen, for the SAS Royal Hotel in Copenhagen, the AJ Lamp family is a classic, which contributed to the modernist style of the hotel, with its graphic lines and simple elegance. The new AJ Garden Bollard with its clean and refined expression, reflects the characteristic design of the family, utilising recognisable angles from the AJ Floor lamp.
Exceptional Light
The shade of the AJ Garden Bollard is painted white on the inside and fixed at the perfect angle to provide soft and pleasant downward directed light.
You might also like
- Variant number
SHORT Spike without power supply LED 3000K 10000163686 SHORT Spike without power supply LED 2700K 10000163687 LONG Spike without power supply LED 3000K 10000163689 LONG Spike without power supply LED 2700K 10000163690 LONG Base without power supply LED 3000K 10000163722 LONG Base without power supply LED 2700K 10000163723 LONG Anchor without power supply LED 3000K 10000163725 LONG Anchor without power supply LED 2700K 10000163726 SHORT Base without power supply LED 3000K 10000163728 SHORT Base without power supply LED 2700K 10000163729 SHORT Anchor without power supply LED 3000K 10000163731 SHORT Anchor without power supply LED 2700K 10000163732 - Mounting instructionsFBXULDLight measurements
