PH 3-2½ Bollard
About the PH 3-2½ Bollard
PH 3-2½ provides a diffused, comfortable light for your outdoor enviroment. The luminaire has a beautiful black powder-coated finish, designed for outdoor use with ingress protection IP44. The luminarie is easily mounted on the ground with the base plate for surface mounting. PH 3-2½ Bollard lets you experience the perfect combination of function and danish design outdoors.
PH 3-2½ Bollard is a member of the three-shade family, Poul Henningsen did not just design a light, but an entire system – around a thousand different models have been produced over the years. This wide selection consisted of table, floor and wall lamps, as well as a number of different chandeliers. Poul Henningsen was the first person to pursue a scientific approach to light and use the logarithmic spiral as a basis. The even light distribution, together with the diffuse reflection through the shades, made it possible to control glare and shadow.
The fixture is designed based on the principle of a reflective three-shade system, which directs the majority of the light downwards. The shades have a matte white painted interior surface, diffusing the light in a comfortable way.
- Light sourceLight source G16.5/candelabraLumen: 720CompliancecULus, Wet location.Other information
Ingress protection class IP44.
IK class: 05.
BUG rating B0-U3-G1.
Controllability: Phase dimming possible.
- Materials
Top shade: Spun stainless steel.
Middle/lower shade: Spun stainless steel.
Shadeholder: Die formed glass.
Post: Stainless steel.
Base plate: Stainless steel.
FinishBlack, powder coated with a matte texture.
- Size (in.): 11.1 (width) x 35.8 (Height) x 11.1 (Length)
- This product is compliant with the requirements contained in the European Directives, RoHS Directive 2011/65 and 2015/863. This product is designed so that 100% of the product can be disassembled and reused. Louis Poulsen is part of ELRETUR which ensures that electronic waste (WEEE) across of Europa is reused. This product must be treated as electronic waste. The product is packaged in a fabric bag and a cardboard box. The cardboard is made from min. 75% recycled fibremass. Additional cardboard material comes from FSC approved sources.Download environmental product information
- Base plate: 6" outside diameter with a 3.54" bolt circle diameter. Surface mounting: Base plate mounted directly to the prepared surface. Anchor bolts: Three (3) supplied anchor bolts, arranged on a 3.54" bolt circle diameter and installed into concrete. Earth anchor: Earth anchor for installation in soil available as a spare part. Download mounting instruction for installation details.Mounting instructions
- PH 3-2½ Bollard/Wall Lamp glass (V2)Item no:5747293382$ 460Anti-Theft screws M8X20Item no:5747293476$ 40Toldbod 155 Bollard / PH 3-2½ Bollard earth anchorItem no:5747293696$ 170
Similar Products
You might also like
- Variant number
35.8" 1xG16.5/candelabra 120V/60HZ 5747940279 49.6" 1xG16.5/candelabra 120V/60HZ 5747940282 - Variant spec sheet [PDF]Light distribution diagrams [JPG]
