LP Icon Opaque
Design by
Mads OdgårdColorNatural Paint Aluminum
$ 3,010
Estimated delivery time: >8 weeks. Contact Customer Service
Lightsource: Built in LED
Free shipping
Free returns
About the LP Icon Opaque
The fixture provides 100% direct downward illumination. Depending on the lenses chosen, the downwardly directed light can be distributed symmetrically or asymmetrically. Optical lenses in front of the LEDs ensure precise light distribution. The reflector surrounding the LED boards and lenses creates a transition from high luminance to lower luminance, thereby reducing uncomfortable contrast.
- Light sourceLight source LED 2700K HILumen: 7918CompliancecULus, Wet location.Other informationLumen: 3750 (LI), 7400 (HI). Dimming options: DALI, CLO, and nighttime dimming (default setting: 50% power in 8 hours). All variants available with Zhaga socket for Smart City compatibility, including CLO and nighttime dimming options. Please contact Louis Poulsen for 2700K.
- MaterialsShade: Light grey opaque acrylic. Housing: Die-cast aluminum. Reflector: Injection-molded plastic (ASA). Diffuser: Toughened clear glass with silkscreen print. A membran for pressure equalization is mounted in the glass.FinishAluminum-colored with textured surface. Powder-coated.
Size (in.): 476 (width) x 422 (Height) x 476 (Length)Weight:30.4 lbs- Post top: Mounts onto horizontal tenon 1.9IN diameter by 3.8IN long. Pair only with LPI-MIN poles.Mounting instructions
- LEDIL BACKLIGHT SHADE KIT ICON HI BLKItem no:5747844676002kr 330LEDIL BACKLIGHT SHADE KIT ICON LI BLKItem no:5747844689002kr 250
- Variant number
SIDE ENTRY LED 2700K HI 7918 DIM 0-10V 5747932973 SIDE ENTRY LED 2700K HI 8174 DIM 0-10V 5747932986 SIDE ENTRY LED 2700K HI 7918 SR NEMA CLO 5747932999 SIDE ENTRY LED 3000K HI 8233 DIM 0-10V 5747933008 SIDE ENTRY LED 3000K HI 8499 DIM 0-10V 5747933011 SIDE ENTRY LED 3000K HI 8233 SR NEMA CLO 5747933024 WIRE TOP-MOUNTED LED 2700K HI 7918 DIM 0-10V 5747933192 WIRE TOP-MOUNTED LED 2700K HI 8174 DIM 0-10V 5747933202 WIRE TOP-MOUNTED LED 2700K HI 7918 SR NEMA CLO 5747933215 WIRE TOP-MOUNTED LED 3000K HI 8233 DIM 0-10V 5747933228 WIRE TOP-MOUNTED LED 3000K HI 8499 DIM 0-10V 5747933231 WIRE TOP-MOUNTED LED 3000K HI 8233 SR NEMA CLO 5747933244 SIDE ENTRY LED 4000K HI 8863 DIM 0-10V 5747938469 SIDE ENTRY LED 4000K HI 9150 DIM 0-10V 5747938472 SIDE ENTRY LED 4000K HI 8863 SR NEMA CLO 5747938485 SIDE ENTRY LED 3500K 76W 8233 DIM 0-10V 5747938508 SIDE ENTRY LED 3500K 76W 8499 DIM 0-10V 5747938511 SIDE ENTRY LED 3500K 76W 8233 SR NEMA CLO 5747938524 WIRE TOP-MOUNTED LED 4000K HI 8863 DIM 0-10V 5747938540 WIRE TOP-MOUNTED LED 4000K HI 9150 DIM 0-10V 5747938553 WIRE TOP-MOUNTED LED 4000K HI 8863 SR NEMA CLO 5747938566 WIRE TOP-MOUNTED LED 4000K HI 9150 SR NEMA CLO 5747938579 WIRE TOP-MOUNTED LED 3500K 76W 8233 DIM 0-10V 5747938582 WIRE TOP-MOUNTED LED 3500K 76W 8499 DIM 0-10V 5747938595 WIRE TOP-MOUNTED LED 3500K 76W 8233 SR NEMA CLO 5747938605 SIDE ENTRY LED 3000K HI 8499 SR NEMA CLO 5747933257 SIDE ENTRY LED 2700K HI 8174 SR NEMA CLO 5747933260 WIRE TOP-MOUNTED LED 2700K HI 8174 SR NEMA CLO 5747933273 WIRE TOP-MOUNTED LED 3000K HI 8499 SR NEMA CLO 5747933286 SIDE ENTRY LED 4000K HI 9150 SR NEMA CLO 5747938498 SIDE ENTRY LED 3500K 76W 8499 SR NEMA CLO 5747938537 WIRE TOP-MOUNTED LED 3500K 76W 8499 SR NEMA CLO 5747938618 - Mounting instructionsULDLight measurements
